Product Name Nylon reducers

材質:UL合格之NYLON66,防火等級94V-2。
用途:此产品可将不同的螺纹外径尺寸进行自由转换; 可根据客户要求定制,生产不同螺纹长度及其他不同螺纹之间的转换。
To allow switching between different thread outside diameter. For example, from large metric external thread to small metric using. We also can make as your request for this product.

型號

外螺紋規格

內螺紋規格

L 螺紋長度

L1 螺紋長度

W 寬度

包裝

Item No.

D1 (鐵板孔徑)

D2 (固定頭尺寸)

Thread length

Thread length

W. across flats

Packing

External threa

Internal thread

NLBJH-M16-M12

M16X1.5

M12X1.5

8

12

22

100pcs

NLBJH-M20-M16

M20X1.5

M16X1.5

8

12

24.2

100pcs

NLBJH-M25-M20

M25X1.5

M20X1.5

10

15

29

100pcs

NLBJH-M32-M25

M32X1.5

M25X1.5

10

15

35.9

50pcs

NLBJH-M40-M32

M40X1.5

M32X1.5

10

15

45.8

25pcs

NLBJH-M50-M40

M50X1.5

M40X1.5

11.5

15

55

25pcs

NLBJH-M63-M50

M63X1.5

M50X1.5

11.5

16

67.5

25pcs
