Thread: G(PF)
Materials: UL approved Nylon PA66PA 66(Flammability UL 94V-2)for C. F parts, Weather-resistant EPDM rubber for . D parts. (Accept to make super rubber: resist high temperature rubber, resist strong acid/alkali,etc).
Working temperature: -40℃ to 100℃
Features: The Powerful Watertight Fittings build the best tightening power by a very high and active compression force to resist the ingress of high pressure water jet from any angle which can provide 100% dynamic waterproof and airtight performance over the widest range of corrugated tubings.
The product can widely applied to resist water impact or immersion as a tough cable protection system for any machines, devices and equipments with the very specific demands.
适配软管
Accommodated Pipes
|
编号
Item.No.
|
螺牙规格
Thread
|
螺纹外径
AG Outer diameter(mm)
|
螺纹长度
Thread Lengt GL
|
包装
Std.Pkg(pcs)
|
|
AD10.0
|
NWTFL-M16-10.0
|
M16X1.5
|
16
|
15
|
50
|
|
AD13.0
|
NWTFL-M20-13.0
|
M20X1.5
|
20
|
15
|
50
|
|
AD15.8
|
NWTFL-M20-15.8
|
M20X1.5
|
20
|
15
|
50
|
|
AD18.5
|
NWTFL-M20-18.5
|
M20X1.5
|
20
|
15
|
50
|
|
AD21.2
|
NWTFL-PF1/2-21.2
|
G(PF)1/2
|
20.9
|
16
|
50
|
|
NWTFL-PF3/4-21.2
|
G(PF)3/4
|
26.4
|
16
|
50
|
|
NWTFL-M25-21.2
|
M25X1.5
|
25
|
16
|
50
|
|
AD25.0
|
NWTFL-PF3/4-25
|
G(PF)3/4
|
26.4
|
16
|
50
|
|
AD28.5
|
NWTFL-PF3/4-28.5
|
G(PF)3/4
|
26.4
|
16
|
50
|
|
AD28.5
|
NWTFL-M30-28.5
|
M30X2.0
|
30
|
15
|
50
|
|
AD34.5
|
NWTFL-M39-34.5
|
M39X2.0
|
39
|
15
|
20
|
|
AD34.5
|
NWTFL-PF1-34.5
|
G(PF)1
|
33.2
|
16
|
20
|
|
AD42.5
|
NWTFL-M47-42.5
|
M47X2.0
|
47
|
24
|
10
|
|
